MODEL:MS-21

In-Wall Audio System with Bluetooth / Wifi / AM / FM / AUX / USB / A/V



 DESCRIPTION



 SPECIFICATIONS
Model Number: MS-21 In-Wall Entertainment System
Power Transformer: AC 120 V AC / 240 VAC switchable
Main Speakers A: 2 pairs 8 ohm speakers / 1 pair 4 ohm speakers
Output Power Speakers A: 45 W x 2 (max) @ 4 ohms, 25 W x 2 (max) @ 8 ohms
Auxiliary Speakers B: 2 pairs 8 ohm speakers / 1 pair 4 ohm speakers
Output Power Speakers B: 45 W x 2 (max) @ 4 ohms, 25 W x 2 (max) @ 8 ohms
Frequency Range: AM 522 - 1710 KHz ; FM 87.5 - 108 MHz
Frequency Response: 20 Hz - 20 KHz
Screen Resolution: 1024 x 600
WiFi: 802.11 b/g/n/ac
Internal Storage: 32GB


 FEATURES
ETL / UL Listed
Andtroid System
Sources: Bluetooth / Wifi / AM / FM / AUX X 2 / USB / A/V (RCA Input)
Smart Radio
Tuner Memory Presets (30 AM & 30 FM)
AM / FM Auto Seek
Digital Audio
10" LCD with HD Video
Internal Strorage for Audio and Video
Full EQ
Zone B Paging
Audio Muting
White semi-gloss finish
New or Existing Construction
Unit Mounts in Standard 2" x 4" Stud Walls (16" On-Center)


 CONNECTIVITY
Inputs:
AUX input X 2
A/V Input (RCA) - May be used for a security camera.
Bluetooth
WiFi
USB port for MP3/WMA files from flash drives
AM/FM antenna input

Outputs:
A+B Speaker Connections with independent controls


 DIMENSIONS & WEIGHTS
Required wall cut-out: 13-1/2" W x 6-1/2" H x 2.5" D
Overall faceplate dimensions: 17-3/8" W x 7-3/8" H
Faceplate Dimension from wall: 1/4" Deep (7/8" Deep w/ knob)

Shipping Dimensions: TBA
Shipping Weight: TBA
Net Weight:  TBA
